OHB Digital XPLORA ONE
XPLORA One presents an affordable GNSS signal generator that is ideal for in-lab testing of general-purpose applications. Its compact and lightweight design, along with ease of use, makes it a suitable choice for anyone seeking to conduct optimal testing of GNSS receivers.
If you're looking for a comprehensive GNSS Signal Simulator solution, XPLORA One is the perfect choice. This all-in-one package includes the XPLORA Core and the Ettus USRP GNSS signal generator, eliminating the need for an additional dedicated GPU/processor. This means it can be connected to any PC or laptop, which is ideal for general in-lab testing. However, XPLORA One's versatility makes it suitable for critical infrastructure, allowing for internal testing of devices that rely on GNSS receivers. With 1 or 2 RF outputs available, XPLORA One offers many of the proven XPLORA Core features in a cost-optimized variant. Choose XPLORA One for a reliable and effective GNSS Signal Simulator solution.
Specifications
Supported GNSS signals
- GPS: L1 C/A, L2C, L5
- Galileo: E1 B/C, E5a-I/Q, E5b-I/Q
- GLONASS: G1 C/A, G2 C/A
- BeiDou: B1, B2
- SBAS: L1 C/A
Bandwidth: up to 120 MHz per RF output
Constellation update rate: up to 250 Hz
Resolution: up to 2 x 16 bit (complex I/Q)
Operating system: Linux
Logging capabilities
- Time related parameters
- Simulated vehicle trajectory parameters
- Receiver antenna parameters
- Satellite trajectory parameters
- Satellite transmit antenna parameters
- Received signal parameters
Automotive add-on: stand-alone web service that allows route planning for road traffic
